led light air fan pcb good reputation OEM pcb reverse engineering china

FOB Reference Price:Get Latest Price
US $1-50 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
SOUNDS
Model Number:
2654.PCB
Base Material:
CEM-1
Copper Thickness:
1oz
Board Thickness:
1.6mm
Min. Hole Size:
0.25 mm
Min. Line Width:
0.3mm
Min. Line Spacing:
5mil
Surface Finishing:
HASL Lead Free
Solder mask:
Green,Yellow,Black,White...
Board layer:
single
Flame retardant standard:
94V-0
Voltage:
120V
Frequency:
60HZ
PCB QC:
E-Test
PCBA QC:
AOI, Function and Burn-in test
Apply to:
fan
Service:
PCB design and PCBA
Key Words:
pcb reverse engineering china
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1.Inner packing :anti-static bag such as red or white bubble bag. Outer packing: standard carton.
2.Protect product with polyfoam and multi-layer paperboard.
3.We can pack as your requirements.
Port
Zhuhai ,Guangdong
Lead Time :
18 working days

pcb reverse engineering china

Product Description

Good reputation OEM pcb reverse engineering china

Model Number

2654.PCB

Surface Finishing

HASL lead free

Min. Line Spacing

5mil

Min. Line Width

0.3mm

Min. Hole Size

0.25 mm

Board Thickness

1.6MM

Copper Thickness

1oz

Base Material

CEM-1

Solder mask color

Green,Yellow,Black,White,Other

Board layer

single

Voltage

120V

Flame retardant standard

94V-0

Frequency

60Hz

PCB QC

E-Test

PCBA QC

AOI test,Function test,Burn-in test

Function

Hot water and cold water control

Working voltage and frequency

120 VAC 60 Hz

Maximum working power

100 W

Remote control range

> 25 feet

Operating temperature range

0 °F (minimum) - 140 °F (maximum)

Apply to

air fan

Service

PCB design and PCBA



Remark: PCB layout can be customized according to customer requirements.

Our product can apply for various of certifications according to customer's requirements,such as: UL ,CE,ETL,TUV...



Main features

1.A thyristor control programme.
2.Timing function: up to seven hours, increment of 1 hour (cumulative: 1,2,4).

3.The IR remote control.
4.LED status indicators   (speed: green, timing: green, negative ion: blue).
5.Negative ion.



Power key
1.Power: ON/OFF

2.Speed: LOW, MEDIUM, HIGH
3.Time: 1 hour each time you press the add, until 7 hours, (then) once closed timing function
4.OSC: ON/OFF
5.ION
Remote control with five and fan function keys, but there is no display.

The fan control panel above all functions are consistent with the remote control.



PCB Details

Item

Description

Capability

Material

Laminate materials

FR-1,FR-4 CEM-1 CEM-3,Alu...

Surface Finish

HASL,ENIG,immersion silver,immersion tin,OSP...

SMT

SMT component size

 0210, 0402,0603,0805,1206

Board cutting

Number of layers

1-16

Min. Thickness for inner layers

0.003”(0.07mm)

(Cu thickness are excluded)

Solder mask

Color

White,black,red,Green,yellow,blue...

Min solder mask clearance

0.003” (0.07mm)

Thickness

0.0005-0.0007”(0.012-0.017mm)

Silkscreen

Color

White,black,yellow,red,blue...

Min size

0.006” (0.15mm)

Board thickness

Standard

0.04-0.16”±10%(0.1-4mm±10%)

Min.

Single/Double layer: 0.008±0.004”

Copper weight

Outer Cu weight

0.5-4 oz

Inner Cu weight

0.5-3 oz

Drilling

Min size

0.0078” (0.2mm)

Drill deviation

±0.002” (0.05mm)

 hole tolerance

±0.002” (0.005mm)

Plating

Min hole size

0.0008” (0.02mm)

E-test

Flying Probe Tester

Yes

Controlled

Tolerance

±10%





Company Information



pcb reverse engineering chinapcb reverse engineering china



Sounds was founded 21 years ago, and it started producing its professional PCBA in 1995.  Sounds is expert in electrical PCBA design and manufacture. It also specialize in adapter and remote controller mass production. “Serve the public, focus on quality” is its motto. Sounds locates in Zhuhai city, Guangdong province. As it known to all, Zhuhai is convenient for export the electrics product. Its valued customer so far----Lasko, Jarden, Honeywell, Kaz and so on.



Production Process



pcb reverse engineering chinapcb reverse engineering china



Sounds has massive force in product design and development. The Engineering Dept has about 20 engineers. For Production Dept, it has 450 workers. Besides, there are 24 production lines for PCBA assembly. What’s more, its perfect equipment of auto-insert machines and surface mounting technology machines process quickly day and night. In the meantime, Sounds has continually improved its factory quality systems and passed ISO9001 and got the certificates of UL, ETL, CE and TUV. For IQC, all materials must up to ROHS standard, some of them must pass Compression Test, Salt Spray Test, High & Low Temperature Circle Test and Burn -in Test.



Quality Assurance



pcb reverse engineering china

Hot Products



pcb reverse engineering chinapcb reverse engineering china



After 21 years of development, its sales volume ups to $25 million per year. Sounds does highly welcome OEM and ODM orders. The management motto of “Develop with Sincerity, Innovation and Progressive” encourage Sounds to keep moving. All in all, a good partner is also trustworthy, Sounds earn your trust and Sounds keep your trust.



Our Certificates



pcb reverse engineering china

Packaging & Shipping



pcb reverse engineering chinapcb reverse engineering chinapcb reverse engineering china
