Fan heater controller pcba/ pcb manufacturer in china, pcb assembly

FOB Reference Price:Get Latest Price
US $1-30 / Pieces | 1 Piece/Pieces PCBA/PCB assembly manufacturer (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
SOUNDS
Model Number:
6221
Base Material:
FR-1(customized)
Copper Thickness:
1oz
Board Thickness:
1.6mm(customized)
Min. Hole Size:
0.15 mm
Min. Line Width:
3mi
Min. Line Spacing:
3mil
Surface Finishing:
HASL lead free
Solder mask:
Green,Yellow,Black,White or other
Board layer:
single
Flame retardant standard:
94V-0
Voltage:
120V
Frequency:
60HZ
PCB QC:
E-Test
PCBA QC:
AOI test,Function test,Burn-in test
Apply to:
fan heater
Service:
PCB design and PCBA
Key Words:
fan heater PCBA
SupplyAbility
SupplyAbility:
1000000 Piece/Pieces per Month PCBA/PCB assembly manufacturer
Packaging & Delivery
Packaging Details
1.Inner packing :anti-static bag such as red or white bubble bag. Outer packing: standard carton.
2.Protect product with polyfoam and multi-layer paperboard.
3.We can pack as your requirements.
Port
Zhuhai ,Guangdong

Product Description

Fan heater controller pcba/ pcb manufacturer in china, pcb assembly

Model Number

6221

Surface Finishing

HASL lead free

Min. Line Spacing

3mil

Min. Line Width

3mil

Min. Hole Size

0.15 mm

Board Thickness

1.6mm(customized)

Copper Thickness

1oz

Base Material

FR-1(customized)

solder mask color

Green,Yellow,Black,White,Other

Board layer

Single

Voltage

120VAC

Flame retardant standard

94V-0

Frequency

60Hz

PCB QC

E-Test

PCBA QC

AOI test,Function test,Burn-in test

Function key

POWER/HI/LOW/OFF;TEMP;OSC

High grade

1500W/all wind speed

Low grade

about 1200 + 100W/half speed

Temperature control range

+ 2 ℉ / - 1 ℉

Apply to

Fan heater

Service

PCB design and PCBA

Remark: PCB layout can be customized according to customer requirements.

Our product can apply for various of certifications according to customer's requirements,such as: UL ,CE,ETL,TUV...



Main features

1)Temperature sensing.

2)Three control buttons.

A. POWER ON/HIGH/LOW/POWER OFF

B. TEMP (green LED lights)

C. OSC

3)The warm air blower’s the above leds are highly recognizable.Color screen makes function are easy to be strong.

4)The temperature setting and display range from 65 ℉ to 65 ℉ (5 ℉ for incremental) plus MAX, a total of 6 green LED lights.

5) When the heater inserted into the AC power source, a light red LED indicator light shine.

6)Low gears with High gear by 2 green LED lights display.High-grade to full power (1500 w), low for two-thirds of slightly upscale power, fan motor in high-end running at full speed, low for two-thirds of slightly high speeds.



PCB Details

Item

Description

Capability

Material

Laminate materials

FR-1,FR-4 CEM-1 CEM-3,Alu...

Surface Finish

HASL,ENIG,immersion silver,immersion tin,OSP...

SMT

SMT component size

 0210, 0402,0603,0805,1206

Board cutting

Number of layers

1-16

Min. Thickness for inner layers

0.003”(0.07mm)

(Cu thickness are excluded)

Solder mask

Color

White,black,red,Green,yellow,blue...

Min solder mask clearance

0.003” (0.07mm)

Thickness

0.0005-0.0007”(0.012-0.017mm)

Silkscreen

Color

White,black,yellow,red,blue...

Min size

0.006” (0.15mm)

Board thickness

Standard

0.04-0.16”±10%(0.1-4mm±10%)

Min.

Single/Double layer: 0.008±0.004”

Copper weight

Outer Cu weight

0.5-4 oz

Inner Cu weight

0.5-3 oz

Drilling

Min size

0.0078” (0.2mm)

Drill deviation

±0.002” (0.05mm)

 hole tolerance

±0.002” (0.005mm)

Plating

Min hole size

0.0008” (0.02mm)

E-test

Flying Probe Tester

Yes

Controlled

Tolerance

±10%
